Monday, October 29, 2012

"Altoid" portable water color tin process

A road test tray and 3 news ones
A cold but perfect morning. Waking up before the sun on a Men's retreat to paint and think.

I have been on a journey to create my version of the perfect pocket tin water color set.  I have really enjoyed the journey and thought I would share it.

 I admit I have really enjoyed researching what others have done.  I want to give credit where credit is due and admit that like any good blues song I have blatantly stole, combined, riffed on, maybe added something....  The ranges go from not painting the tin and rubber cementing trays and half trays, to using sculpey clay, to very elaborate.  I didn't mean for my process to go the involved route, but hey, when you are having fun and find you can make exactly what you are looking for.....

I have always used a half pan Winsor & Newton Cotman Watercolor - Compact Set and I have always done the urban sketchers type of on site painting. My wife taught me to paint in Rome while there during architecture school and I have used this kit ever since.

Iphone process photo from the Metro Sketchers outing at the state fair this year. Yes that is the arts building. (perhaps one day I will have something in there?)

There are things I love about this kit. Including the memories with using it. But I wish it was smaller and honestly, since I didn't create the color palate, I didn't really know how to use most of the color. I have been on a concurrent crusade to understand color while making this kit and the color choices used in the tins will reflect that, but more on color later. But honestly, this cost me 30 or so bucks in 1998 and I have sooo enjoyed it and still will.

 On to the making

The Tins

Like I said, I did a lot of thinking first and a lot of research.  I decided I wanted the following:
1.  I wanted to go the sculpey clay route (moldable clay you bake for 30 min - pretty cheap - about 7 bucks worth made about 4 trays for me)
2.  I wanted to paint the tins so I didn't deal with rust and I wanted a white mixing backdrop.
3.  I wanted to steal an idea I saw using bathroom caulk to make mixing trays on the lid.
4. I  wanted to make one large tin and one small tin.

And during the process this is where it clicked....This is when I started to get excited.  This is where I answered the question...why not just buy the little KOI kit (that comes with the little water brush I couldn't find and seems like a great kit.)
5.   Once I started making the sculpey trays I decided I would enjoy being able to take them out and use both surfaces of the tin to mix with.

Then I realized I could reasonably stack two trays in one tin.

Now we are making something we can't buy...I am in....

Altoids have become the household name for these tins, BUT they started embossing the logo into the lid. So I found a Newman's own brand that had a flat top. I bought a large and a small. I have played with these for hours, but still haven't gotten through all of the mints!
To Start
Prepping the Tins.  Following other's advice I :
1. Thoroughly washed the tins
2. Bought some (Walmart) white appliance paint
3. Heated the tins up to 200 or so degrees
4.  Put them in a shoe box
5.  And spray painted the crap out of them. I was surprised that even with doing multiple small coats the original color still sneaked through.  The lesson here is to use more paint than you think you need.

The Clay
I bought the super premo white sculpey from Dick Blick. I bought two small packs and it was enough plus a little to do everything you see here.  My sculpting is rough, but I love the experimental phase.  I learned a little about warping too, but more on that toward the middle of the process.
I started thinking I would use the entire bottom of the tray.  I used the half pans from my cotman kit as a starting point.

Then I realized half the tin was all that I needed and I would still have space for my brushes and pencil.  In the beginning I was going for tight fit, but removable for cleaning. Now I go for ease of taking in and out of the tin.

At this point I had decided to cut the tin in half.  Next I started cutting in the half trays from my kit.  I decided not to use the trays. I just use them for the shape and then fill with tube paint. I dries well enough to travel within a couple of hours. Hasn't been a problem, and this first kit even survived me dumping a Kayak with this kit in my pocket.

BTW, I think all the oil from the clay may have made my paint more prone to water color (especially blue) staining.  I have made several trays but not new tins to see if this is true or not.

 On the lid and the small tin I used the caulk trick to separate mixing trays and make the paint wells on the smaller tin. I used a regular full size caulk gun.  This was much more difficult to make even close to pretty and I had to form it with a paint knife quite a bit. I think a smaller tube of caulk would make this much easier. Going though old car model stuff lately I found a putty they use to build stuff up. This tube I have is over 20 years old, but I think I will see if it is still good on the next round.

The finished and baked tray. Notice how thick the sides are?  This one did not warp. My later ones were smaller and did warp a bit. The warping is fine except it makes is thicker for no good reason so closing the lid becomes hard now. Symmetry about the sides is the key.

 The finished tray - both "large" and small.

 Now to load them up with color.  Inspiration to me Cathy Johnson has a wonderful blog, and information specifically about this. She was smarter and took the simpler approach, but she does talk alot about limited color choices and I used that model.  She has two approaches and they are both represented here.


 Test drive at home....
Test drive in the field
 And test drive at the kitchen table (My Inlaws in Bella Vista Arkansas doing a study of an amazing national steel guitar)

 At the coffee shop (Mauve's in NE Minneapolis)

So...As I said, now I am making something I can't buy....AND I HAVE CLAY LEFT OVER....and I have played with it awhile.

I have thought alot about mixing space and in a small working area how to keep you colors clean.  I have been thinking about sloped paint wells where the pure stuff stays up top, and you can play with color mixtures down below.  I had a couple of ideas and roughed them out. I started the same way as before, using the half pan from my cotman kit to space things out, but started carving from there.

progress shots.....

This tray has a single slope

 This tray has a double slope

After baking the first two warped a little. I wasn't careful about keeping a consistent edge

 After baking

  ...So on the third one I added a small skillet during cooking to make it flat. I underestimated the weight and the heat, but it is still usable and has this cool impression on the back...but it is a bit squished...BUT STILL USABLE!

 My new arsenal

 I have only test driven these in at my table so far

I have loaded these up based on distinctions made in "Making color sing" seperated by transparents, vivid staining, and very opaque.  For now this is working for me and I use a sharpie to give the same abbeviations for the studies. I know that I will change this arrangement later on with a little soap and hot water...

This blog entry is long enough. I want to talk about color choices and the pen brushes on later post.

I hope this helps and maybe I have added to the great conversation.  I am certainly enjoying my custom kit.

Sunday, October 7, 2012

Metro Sketchers - Lakewood Cemetery sketch out

Fall colors

I am really going to miss the leaves when they are gone. This year if embracing color understanding has made this year the most beautiful I can remember. I see things differently now.

Someday I will be patient enough to wait till these things dry.

Thursday, October 4, 2012

The Pumpkin Process..maybe too much process

 I love love love process shots. Plus I love the golden mean.  Maybe I use it too much...but it works for me. Often I will layout a golden rectangle first. I will say every building I have ever designed this way (I work the foot print and elevation until is matches a masonry dimension and from there everthing "lines up" and I get more feedback..more on that later.. but proportion really means relationship and relationship is everything)
 I started yesterday morning in my mens group (my turn to lead) getting people to draw and preached my allegiance to proportion so I thought I would show it in a way I typically just incorporate (vs put it in red pencil)
 The first sketch out. I have been drawing this same pumpkin in my study of "making colors sing" for the past few weeks. The pumpkin should be glad because squirrels have taken 3 bites and then left every other pumpkin in our garden.
 Working out the shadows given two light sources
 Finish the sketch, then the tough part, getting this onto the watercolor paper. This sketch was done on trace paper, the next step is to sketch under the trace paper while holding it in place. Kind of clumsy but it works well enough with touch up.
 The under trace and the trace sketch. I really like the trace sketch and may keep it.
 Time to touch up the undertrace on the real paper
 I have to include my buddy who is drawing beside me. Way past his bed time, but if he is drawing with me...I will break the rules a little!  He is quite good, but both parents draw all the time in front of him.
 Wook it Daddy!
 The best part of Leo's sketches is that they come with a story. A great story
 And it gets pretty elaborate. Plus, I need to burn time while my paint dries

 I did the yellow first because I read that yellow afterwards muddies things. On teh dry parts I started to use blue. The point is undertones that will be knocked down by cadmium orange later. Cadmium Orange has two advantages. The rest of this palate is really transparent and it is a very opaque, plus it happens to the the exact color of my pumpkin!
 Working on the shadows on my green glass table
 I cheated and added transparent yellow because it middle ground the yellow and eventual orange.  Everyone seems to love transparent orange. I now know why. I squeezes out as mustard ochre but with water becomes the exact color of a good beer (say a Boddingtons) anyway I thought is would be a good bridge to the last step
 Working it more and showing the model

 Alittle more shadow work
 Adding the Cad Orange in layers
A semi wet finished product. I have learned I need to wait a few hours for the final and nice things happen as the paint settles out and makes friends. I will take a final picture tomorrow for the final.

I am really enjoying the making colors sing palate.

Tough day, fun night of painting. During this project I fed a kid, loaded and unloaded a dishwasher, watched the news, cleaned a kitchen, paid bills. Some decent multitasking if I do say so myself.
